DN

PN1.6/2.5/4.0MPa,Class 150Lb/Class 300Lb

WT(Kg)

L

d

G

D

D1

H

W

10

80

10

3/8”

45

31.2

72

140

0.62

15

90

10

1/2”

48

34.6

76

140

0.87

20

100

13.5

3/4”

58

41.6

81

160

2

25

115

18

1”

66

53.1

92

180

4

32

130

22

11/4”

80

63.5

112

200

5

40

150

26

11/2”

9

69.3

121

250

7.5

50

180

32.8

2”

114

86.5

137

300

10
